Switchroom Platform Stairs
Just a small project for a client’s requirements, finished quickly and with no comments. Custom handrails, bought-out stanchions, made to align to a existing structure and modified accordingly.
-
11kV Substation
Applied NZS in stair rises and runs and created custom models and details for handrails according to stanchion provider specifications. Purlins modeled with lengths and holes as per manufacturer’s specifications and implemented in BOM (Summary Lists) for client’s ease of acquisition and assembly. The rest of the steel structure modeled and detailed without problems. Drawings…
